Flexo Surface Ink (SF)

Characteristics:
1- Alcohol is the main solvent in the formula, and the ink exhibits very low toxicity as well as low solvent retention.
2- Good printability, and easy operation.
3- Vivid color, high color saturation, and excellent fine tones.
4- General purpose, and can be printed on a versatile substrates.

Recommended film:
PET -------------------------------------- surface tension higher than 48 dyne
BOPP ------------------------------------ surface tension higher than 38 dyne
CPP -------------------------------------- surface tension higher than 38 dyne
PP/PE Woven bags.

Reducer:



Solvent

A

B

C

Iso-propanol

40

70

-

N-propanol

-

-

50

Ethyl acetate

60

30

-

N-propyl acetate

-

-

50



100

100

100

Reducer type

Fast drying

Standard

Slow drying

Recommended printing pattern

Full background solid color

Solid color

Process printing


Printing viscosity: White ink: 17 – 20 sec/zahn2/25oC; Color ink: 19 – 22 sec/zahn2/25oC .
Printing viscosity needs to be adjusted according to different printing condition.


Standard color:



Code

Color

Code

Color

Code

Color

T61

White

D92

Black

T82

Violet

D3

Orange red

D8

Dark red

D16

Purple Red

V20

Medium yellow

V22

Reddish yellow

V23

Greenish yellow

C53

Orange

H173

Rose

X33

Dark blue

X38

Process blue

X391

Blue

X79

Green


Note:
1- The heat resistance of sf series is less than 120oC.
2- The ink will gel under low temperature, but it can come back when using hot water or vapor to heat ink without sacrificing the performance. Avoid heating the ink directly with fire, which may cause fire.
3- When under higher humidity (> 90%) and low temperature (< 10%), whiteness may appear on the printed ink. To avoid this, higher oven temperature is needed and also need to add some low evaporation solvent as n-Propyl Acetate, and Methoxy Propanol.
